Whirlpool WWPB8502IW 8kg/4.5kg White SteamCare Slim Washer Dryer Combo

• Steam Hygiene: uses the natural power of steam to help remove 99.99% of bacteria (tested by SGS, report SHES240801641471) while softening and gently hygienising fabrics.
• FreshCare+: periodically releases steam and tumbles the load for up to 6 hours after the cycle ends, so laundry doesn't need to be unloaded immediately.
• Steam Refresh: a quick programme that lifts odours and smooths creases, leaving clothes damp and ready to hang.
• Compact Design: an 820mm height suits built-under installations without removing the top of the unit.
• Slim Depth: a 475mm depth and 8kg wash capacity help it fit into tighter laundry spaces.
• AutoStart: press and hold Start/Pause for 3 seconds to automatically detect the load (up to 8kg) and begin a wash cycle.
• Antimicrobial detergent drawer: the detergent drawer and surrounding bellow are treated to resist 99% of bacteria (tested by TÜV SÜD, Chinese Academy of Sciences).

• Mixed 55': For washing lightly to normally soiled garments in cotton, linen, synthetic fibres and mixed fibres.
• Speed 15': For quick washing of a small load or lightly soiled garments.
• Cotton: For washing normally soiled cotton garments; at 40°C this is the standard cotton programme and the most efficient for water and energy consumption.
• Steam Refresh: For refreshing clothing and relaxing fibres. Clothing will be damp once finished — do not add softeners or detergents.
• Allergy Care: For high-temperature washable clothing such as cotton and linen.
• Drum Clean: For cleaning the drum only, using high temperature to sterilise the drum and remove dirt. Do not add clothes or detergent when using this programme.
• Spin & Drain: Spins laundry and drains the water.
• Wool: For washing wool garments; use a special detergent and do not exceed the maximum load.
• Hot Air Refresh: For refreshing clothing and removing bad odours with hot air. Do not add softeners or detergents.
• Dry Only: For drying without a wash cycle.
• Wash & Dry 60': For washing and drying cotton and synthetic fabrics quickly.
• Speed button: Sets the spin speed; the range varies by programme. Long press for 3 seconds to set the Delay Finish time, up to 24 hours.
• Dry button: Selects the drying mode and drying time.
• Steam button: Activates or deactivates the steam function. Long press for 3 seconds to activate FreshCare+.
• Temp button: Sets the wash temperature according to the fabric type; the range varies by programme.
• Child Lock: Long press the Temp button for 3 seconds to activate.

• Model: WWPB8502IW
• Washing Capacity: 8kg
• Drying Capacity: 4.5kg
• Colour/Finish: White, Dark Grey Door
• Drum: Stainless Steel
• Motor Type: Brushless Inverter Motor
• Maximum Spin Speed: 1400rpm
• Display: LED
• Control: Touch
• Safety Features: Child Lock, Door Lock
• Other: Antimicrobial detergent drawer and bellow
• WELS Water Rating: 4 stars (78 litres per wash) - In accordance with AS/NZS 6400
• Energy Rating: 4.5 stars (Wash, 250 kWh per year), 3 stars (Dry, 171 kWh per year)
• Rated Water Pressure: 0.03–1.0MPa

• Installation type: Freestanding installation; suits built-under installations without removing the top of the unit.
• Placement: Install on a flat, hard, non-carpeted floor with a minimum clearance of 10cm from the wall. Remove and retain all transport bolts and the base protector before use.
• Power supply: Requires a 220-240V, 50Hz power supply.
• Rated power: 1750W rated power draw (wash), 1500W rated drying power.
• Connection type: Australian Type I plug.
• Water inlet hose: Supplied inlet hose measures 1400mm.
• Water outlet hose: Supplied outlet hose measures 1700mm.
• Electrical cord: Supplied electrical cord measures 2000mm.
• Water pressure: Requires a rated water pressure of 0.03–1.0MPa.

Warranty coverage

Whirlpool appliances are distributed in Australia by Arisit Pty Limited and are backed by a 2-year manufacturer's warranty, giving you confidence in the quality and performance of every appliance across their range of kitchen and laundry products.

• All Whirlpool appliances (refrigerators, dishwashers, washing machines, dryers, cooktops, rangehoods, ovens, freestanding cookers & microwaves): 2 years — Defects in materials and workmanship, domestic use only

Proof of purchase is required for all warranty claims. To activate your warranty, register your product within 30 days of purchase at whirlpool.com.au. The warranty is transferable to a subsequent owner within the warranty period, provided Whirlpool is notified in writing with the new owner's details.

What's covered

• Manufacturing defects in materials and workmanship
• Repair or replacement of faulty products or parts within the warranty period
• Replaced or repaired components carry the remaining warranty period or 3 months, whichever is greater

What's not covered

• Incorrect installation or failure to follow manufacturer instructions
• Misuse, accidental damage, neglect, or abnormal use
• Damage from fire, water, vermin, insects, or external electrical faults
• Blockages caused by foreign objects
• Cosmetic damage that does not affect the functioning of the product
• Consumables such as light bulbs, filters, and other wear items
• Unauthorised modifications or repairs
• Commercial use of domestic appliances
• Inadequate or incorrect venting
• Excessive use of cleaning products or cleaning agents

Conditions

• Cooktops, ovens, and rangehoods must be installed by a licensed electrician or gas plumber
• Must be used and maintained in accordance with the Use and Care Guide or Instruction Manual
• Product must be registered within 30 days of purchase at whirlpool.com.au to activate the warranty
• Any transport damage must be reported within 7 days of delivery
• Proof of purchase must be provided with all claims
• The warranty is transferable to a subsequent owner provided Whirlpool is notified in writing within a reasonable time of the sale, with the new owner's name, contact details, place and date of purchase, and model and serial number

Making a claim

Contact Arisit on 1300 762 219 or submit a service request at whirlpool.com.au. For large appliances (refrigerators, dishwashers, washing machines, dryers, cooktops, rangehoods, and ovens), an authorised Whirlpool service technician will be sent to assess the claim. For smaller appliances such as microwaves, you may be asked to bring the product to your nearest authorised service agent. Please have your model number, serial number, and proof of purchase ready when submitting your claim.

Australian Consumer Law

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure.

The WWPB8502IW's 820mm height and 475mm depth make it one of the more compact washer dryer combos in Whirlpool's Australian laundry range, suited to built-under installations and smaller laundries. We suggest running the Drum Clean programme before the first wash.

Actual drying performance and overall cycle duration vary with load size, fabric type and the programme selected. As with any washer dryer combo, avoiding overloading the drum and using the recommended detergent type help the wash and hygiene features perform as intended.
