Product Description

Product Overview:

The Robam 87H5S 90cm Motor CleanAir 3rd Generation Integrated Rangehood combines high-performance recirculating ventilation with an ultra-slim concealed design, making it ideal for contemporary kitchens where both aesthetics and functionality are equally important. Designed to integrate neatly within overhead cabinetry, the rangehood remains virtually hidden while delivering powerful extraction performance that effectively removes cooking smoke, grease, odours and airborne contaminants. Its compact profile also frees up to 60% more overhead cabinet storage compared with conventional concealed rangehood designs, helping maximise valuable kitchen storage space.

At the heart of the 87H5S is ROBAM's third-generation CleanAir technology, developed specifically for homes where external ducting is limited or impractical. The advanced recirculation system incorporates an air purifier-grade activated charcoal filtration system designed to capture cooking odours, grease particles and harmful airborne pollutants before returning cleaner air back into the kitchen. This makes the rangehood particularly well suited to apartments, townhouses and modern homes where recirculation is preferred without compromising extraction performance.

Powered by a high-efficiency BLDC brushless motor, the rangehood delivers unrestricted airflow of up to 2400m³/hr while Intelligent Smart Speed Control continuously monitors duct resistance and automatically adjusts motor performance to maintain optimum airflow and static pressure. AI Gesture Control allows touch-free operation with a simple wave of the hand, while integrated Bluetooth R-Link™ technology communicates directly with compatible ROBAM cooktops, automatically activating and adjusting extraction during cooking before switching off when cooking is complete. Additional premium features including the Fresh Air System, Daikin OPTOOL™ anti-stain coating and non-stick internal surfaces further reduce maintenance while keeping the kitchen environment cleaner between cooking sessions.

Product Features:

• CleanAir™ 3rd Generation Technology: Premium recirculating ventilation system featuring air purifier-grade charcoal filtration for cleaner indoor air.
• 2400m³/hr unrestricted airflow: High-capacity extraction designed to rapidly remove smoke, grease and cooking vapours.
• 1380m³/hr IEC airflow: Certified airflow performance measured under IEC testing standards.
• BLDC brushless motor: High-efficiency motor providing powerful extraction while reducing operating noise and energy consumption.
• Smart Speed Control: Intelligent sensing technology automatically adjusts extraction performance according to duct resistance to maintain optimum airflow.
• AI Gesture Control: Operate fan functions with simple hand gestures without touching the appliance.
• Bluetooth R-Link™: Automatically synchronises operation with compatible ROBAM cooktops.
• Automatic cooktop activation: Rangehood starts automatically when paired cooktops begin cooking.
• Automatic shut-off: Extraction automatically switches off once compatible cooktops are turned off.
• Fresh Air System: Periodically refreshes kitchen air to minimise stale odours and maintain a healthier indoor environment.
• Daikin OPTOOL™ exterior coating: Anti-stain surface improves scratch resistance while simplifying everyday cleaning.
• Non-stick internal coating: Helps reduce grease adhesion inside the rangehood for lower maintenance.
• Ultra-slim concealed installation: Integrates neatly within cabinetry for a streamlined kitchen appearance.
• Space-saving design: Releases up to 60% additional overhead cabinet storage.
• Tempered glass and stainless steel construction: Durable premium materials designed for long-term kitchen use.
• Three fan speeds: Select extraction performance to suit light simmering through to high-heat cooking.
• Maximum static pressure of 1200Pa: Maintains strong airflow performance even under higher ventilation resistance.
• Quiet operation: Maximum operating noise of 57dB(A), with low-speed operation down to approximately 42dB(A) on the global model specification.
• Delay shut-off function: Continues ventilation after cooking to assist with residual odours.
• Gen 3 Wave Control: Third-generation touchless motion sensing improves responsiveness and convenience during cooking.

Colour / Finishes:

• Glossy Black — CXW-260-87H5S
• Glossy White — CXW-260-87H5SW
• Matte Grey — CXW-260-87H5SY

Programmes / Functions:

• Smart Speed Control: Automatically adjusts suction power to maintain optimum airflow and ventilation performance.
• AI Gesture Control: Adjusts fan operation with a simple hand wave for touch-free control.
• R-Link™ Cooktop Sync: Automatically starts and stops the rangehood when paired with a compatible ROBAM cooktop.
• Fresh Air System: Periodically refreshes indoor air to help reduce lingering odours and airborne pollutants.
• Delay Shut-Off: Continues extracting residual smoke and odours for a short period after cooking before switching off automatically.
• CleanAir™ 3.0 Recirculation: Purifies and recirculates kitchen air through an activated charcoal filtration system.

Cleaning & Maintenance:

• Daikin OPTOOL™ Nano Coating: Anti-stain exterior coating allows fingerprints, grease and marks to be wiped away with minimal effort.
• Non-Stick Interior Coating: Helps prevent grease from adhering to internal surfaces, reducing cleaning requirements.
• Wash-Free Interior Design: Non-stick internal surfaces minimise grease build-up, reducing the need for internal disassembly during routine maintenance.
• Baffle Grease Filter: Durable baffle filter captures grease particles and is designed for long-term performance.
• Activated Charcoal Filter: CleanAir™ recirculation filter should be replaced periodically to maintain optimum odour removal performance.

Specifications:

• Product type: Integrated Rangehood
• Series: CleanAir™ 3rd Generation
• Installation type: Integrated concealed installation
• Ventilation type: Premium recirculating ventilation
• Filtration system: Air purifier-grade activated charcoal filtration
• Motor type: BLDC brushless motor
• Motor power: 260W
• Airflow (Unrestricted): 2400m³/hr
• Airflow (IEC Standard): 1380m³/hr
• Maximum static pressure: 1200Pa
• Maximum noise level: 57dB(A)
• Low speed noise: Approximately 42dB(A)
• Fan speeds: 3
• Smart Speed Control: Yes
• AI Gesture Control: Yes
• Bluetooth R-Link™: Yes
• Automatic cooktop synchronisation: Yes
• Fresh Air System: Yes
• Delay shut-off: Yes
• Wave Control: Generation 3
• Lighting: Integrated LED
• Build material: Tempered glass and stainless steel
• Grease separation efficiency: 99%
• Glass panel finish: Variant dependent
• Electrical supply: 220–240V
• Frequency: 50–60Hz
• Duct configuration: Convertible platform
• Filter type: Baffle filter with CleanAir charcoal recirculation system.

Product Measurements:

• Overall Dimensions (W × D × H): 895 × 510 × 560–880 mm
• Product Width: 895 mm
• Product Depth: 510 mm
• Adjustable Height: 560–880 mm
• Cabinet Width Required: Suitable for 900 mm overhead cabinetry
• Installation Configuration: Fully integrated concealed installation


Product Weight:

• Net Product Weight: 23.6 kg

Installation & Requirements:

• Installation Type: Fully integrated concealed rangehood.
• Ventilation System: CleanAir™ 3rd Generation premium recirculating system.
• Electrical Supply: 220–240V AC.
• Frequency: 50–60Hz.
• Motor Power: 260W BLDC brushless motor.
• Designed for installation within overhead kitchen cabinetry.
• Requires adequate cabinet ventilation in accordance with the installation guide.
• Charcoal filtration system designed for recirculating operation without external ducting.
• Smart Speed Control continuously monitors airflow resistance to optimise extraction efficiency.
• Bluetooth R-Link™ functionality requires a compatible ROBAM cooktop.
• AI Gesture Control sensor should remain unobstructed for reliable operation.
• Fresh Air System operates automatically to circulate kitchen air between cooking sessions.
• Installation should be completed by a suitably qualified installer in accordance with local electrical regulations.
• Refer to the official installation guide for cabinet dimensions, minimum clearances and service access requirements.

Country of Origin:

• Made In China

Extra Information:

Unlike conventional recirculating rangehoods that primarily focus on grease removal, ROBAM's CleanAir™ 3rd Generation technology has been engineered to improve overall indoor air quality. The advanced activated charcoal filtration system is designed to reduce cooking odours while helping capture fine airborne particles generated during cooking, making it particularly suitable for apartments and modern homes where external ducting is either undesirable or impractical.

The integrated BLDC brushless motor provides strong extraction performance while consuming less energy than conventional AC motors. Combined with Intelligent Smart Speed Control, the system automatically compensates for airflow resistance, maintaining consistent extraction performance throughout the cooking process without requiring manual adjustment.

AI Gesture Control enables users to adjust extraction levels using simple hand movements, reducing contact with the control panel during cooking. When paired with compatible ROBAM cooktops via Bluetooth R-Link™, the rangehood can automatically activate when cooking begins, adjust extraction according to cooking intensity and continue operating after cooking has finished before shutting down automatically.

The Fresh Air System periodically exchanges indoor air even when the appliance is not actively extracting cooking fumes. This automatic ventilation cycle helps minimise lingering kitchen odours and contributes to a fresher indoor environment throughout the day.

The exterior is finished with Daikin OPTOOL™ technology, providing a highly durable anti-stain surface that resists fingerprints and everyday marks. Internally, a non-stick coating reduces grease adhesion, simplifying routine maintenance and helping preserve extraction efficiency over time.

With its ultra-slim profile, the 87H5S occupies significantly less cabinet space than many traditional integrated rangehoods, allowing up to 60% more usable overhead storage while maintaining powerful ventilation performance. This combination of concealed installation, intelligent automation and premium recirculation technology makes it well suited to contemporary kitchen designs where both aesthetics and functionality are priorities.

Included Products / Accessories:

• Integrated rangehood unit.
• CleanAir™ activated charcoal filtration system.
• Aluminium grease filter assembly.
• Integrated LED lighting.
• Mounting hardware.
• Installation instructions.
• User manual.

Warranty:

Robam rangehoods are backed by a 10 year warranty on the motor and a 2 year warranty on parts. Cooktops, ovens, dishwashers, and microwaves carry a 2 year manufacturer's warranty on parts and labour. All warranties are in addition to your rights under the Australian Consumer Law.

Downloads / Product Files:

• USER MANUAL (PDF)
