Product Description
Product Overview:
The Oliveri VE1085-TK Venice Straight Wall Mixer Set Trim Kit provides the visible components required to finish a compatible Series 2 concealed wall-mixer installation. Its straight spout, pin-lever handle and compact wall plates create a clean architectural arrangement for contemporary basins and baths.
This trim-only package is designed for use with the separately purchased Oliveri UNI-C2-BY in-wall body. Made from lead-free brass with a zinc handle and stainless-steel lever, it includes a WELS 6 Star 4.5L/min aerator installed and an optional WELS 5 Star 6L/min aerator.
Product Features:
- Trim kit only: Completes a previously installed compatible Series 2 in-wall body.
- Straight adjustable spout: Provides a finished projection of 182–204mm.
- WELS: 6 Stars at 4.5 litres per min
- Interchangeable Series 2 format: Designed specifically for the UNI-C2-BY body.
- Five Venice finishes: Coordinates with the wider collection.
Colour / Finishes:
- Chrome - VE108500FCR-TK
- Gunmetal - VE108505FGM-TK
- Matte Black - VE108516FMB-TK
- Classic Gold - VE108503FCG-TK
- Brushed Nickel - VE108504FBN-TK
Cleaning & Maintenance:
- Routine cleaning: Use mild liquid detergent or warm soapy water with a soft cloth.
- Rinse and dry: Remove residue and dry after cleaning.
- Protect the finish: Avoid cream, citrus, abrasive and acid-based cleaners.
- Aerator care: Retain the certified flow regulator when servicing.
Specifications:
- Brand: Oliveri
- Model family: VE1085-TK
- Collection: Venice
- Product type: Wall mixer set trim kit
- Installation: Wall mounted
- Compatibility: Oliveri UNI-C2-BY in-wall body
- Material: Lead-free brass body, zinc handle and stainless-steel lever
- Operating pressure: 150–500kPa
- Temperature rating: 1–65°C
- WELS: 6 Stars at 4.5 litres per min
- WELS registrations: T43990
- WELS licence number: 1416
- Compliance: In accordance with AS/NZS 6400
Product Measurements:
- Finished spout projection: 182–204mm
- Mixer handle projection: 72–115mm
- Wall plates: 44mm diameter
- Mixer-to-spout centre distance: 277mm
Product Weight:
- Net product weight: 0.65kg
Installation & Requirements:
- Required body: Must be fitted to an Oliveri UNI-C2-BY in-wall body, sold separately.
- Licensed installation: Final fit-off must be completed by a licensed plumber.
- Compatibility check: Confirm the concealed body and wall set-out before ordering the trim.
- Operating conditions: Suitable for mains pressure from 150–500kPa and temperatures from 1–65°C.
Extra Information:
The trim-only format allows the visible finish to be selected after the concealed UNI-C2-BY body has been installed. This is particularly useful during staged renovations, where the plumbing rough-in occurs before final colours and surface selections are confirmed.
The VE1085-TK is not a complete working mixer by itself. Pair it with the correct Series 2 body and verify the installed set-out so the straight spout lands comfortably over the chosen basin or bath.
Included Products / Accessories:
- Venice trim components: Straight spout, backplates, handle, cartridge sleeve and dome cover.
- 6 Star aerator: Installed for 4.5L/min operation.
- 5 Star aerator: Included for optional 6L/min operation.
- Important: UNI-C2-BY in-wall body is not included.
Warranty:
Oliveri products are backed by a comprehensive manufacturer's warranty, including lifetime cover on selected stainless steel kitchen sinks, laundry tubs and basins, 20 years on selected vitreous china basins and toilets, and 15 years on selected bathroom tapware and shower bodies. Warranty periods vary by product category and are in addition to your rights under the Australian Consumer Law. Refer to the Oliveri Warranty page for full terms and conditions.
Downloads / Product Files:
