Product Description

Product Overview:

The Kleenmaid CRZ27011 is a fully integrated 267L refrigerator with a bottom-mount freezer, designed to sit behind matching kitchen cabinetry for a streamlined built-in finish. Its storage is divided between a 193L refrigerator and a 74L freezer, providing practical everyday capacity within a 540mm-wide appliance footprint.

No Frost cooling removes the need for routine manual defrosting, while a brushless direct-current fan circulates cooled air through the cabinet to maintain stable storage conditions. ULTRAFreeze delivers an additional cooling boost when rapid freezing is required, and the 4.5-star MEPS energy rating combines efficient operation with a quiet 35dBA sound level.

Electronic touch controls provide separate refrigerator and freezer temperature adjustment, complemented by LED interior lighting, adjustable toughened-glass shelving and a concealed low-temperature beverage compartment. Kleenmaid’s KwikFit installation system, commercial-grade concealed hinges and reversible door configuration support flexible integration into new or renovated kitchens.

Product Features:

• Fully integrated configuration: Installs behind customer-supplied cabinetry panels for a continuous kitchen finish.
• 267L net capacity: Combines a 193L refrigerator compartment with a 74L bottom-mount freezer.
• No Frost cooling: Uses air cooling and automatic defrosting to prevent routine ice build-up.
• Brushless DC fan motor: Circulates cooled air evenly through the appliance while supporting quiet, efficient operation.
• ULTRAFreeze: Applies additional cooling to accelerate freezing when new groceries are added.
• 35dBA operation: Keeps operating noise low for open-plan kitchens and adjoining living areas.
• 4.5-star energy rating: Ultra-efficient insulation supports strong energy performance under Australian MEPS testing.
• Electronic touch controls: Provides clear adjustment of refrigerator and freezer temperatures from the internal display.
• Adjustable toughened-glass shelving: Allows storage height to be reorganised around everyday groceries, tall containers and serving items.
• Flexible freezer tray: The sliding pizza and frozen-dessert tray can be vertically reversed to increase usable drawer space.
• Reversible doors: Supports left- or right-hand opening without additional hinge components.
• Full metal cabinet: Provides a robust appliance enclosure designed for durability and electrical safety.

Colour / Finishes:

• Fully Integrated - CRZ27011

Programmes / Functions:

• Refrigerator temperature control: Selects refrigerator temperatures from 2°C to 8°C; the manufacturer’s factory setting is 5°C.
• Freezer temperature control: Selects freezer temperatures from -24°C to -16°C; the manufacturer’s factory setting is -20°C.
• Super Cooling: Temporarily increases refrigerator cooling performance and exits automatically after six hours.
• ULTRAFreeze / Super Freezing: Provides an intensified freezer setting for rapidly cooling newly added food.
• Vacation Mode: Changes operating behaviour for periods away from home and disables the door-open alarm while active.
• Door-open alarm: Sounds when the refrigerator door remains open for more than two minutes.
• Setting memory: Retains the last-used settings after the appliance has operated continuously for more than 30 minutes.

Cleaning & Maintenance:

• Disconnect before cleaning: Unplug the appliance before cleaning or carrying out user maintenance.
• Removable door trays: Lift the door trays out for washing, then reinstall them at the required height.
• Glass shelves: Raise the front of each shelf to release it from the rear stop before removal and cleaning.
• Fruit and vegetable box: Pull the box fully forward, lift it and remove it for cleaning.
• Long periods of non-use: Unplug and clean the appliance, then leave both doors open to help prevent odours.
• Automatic defrosting: The air-cooled system defrosts automatically; seasonal frost can be addressed only as directed in the user manual.

Specifications:

• Brand: Kleenmaid
• Model: CRZ27011
• Product type: Fully integrated refrigerator with bottom-mount freezer
• Total net capacity: 267L
• Refrigerator capacity: 193L
• Freezer capacity: 74L
• Cooling system: No Frost with cooled-air circulation
• Fan motor: Brushless direct current
• Energy rating: 4.5 stars
• Energy consumption: 225kWh per year
• Noise level: 35dBA
• Refrigerant: R600a
• Power supply: 220–240V AC
• Rated defrost power: 185W
• Full-load current: 1.2A
• Electrical connection: 10A plug and cord
• Door hinging: Reversible
• Controls: Electronic touch controls
• Cabinet construction: Full metal cabinet

Product Measurements:

• Overall dimensions (W × D × H): 540 × 550 × 1785mm
• Cabinet matching depth: 515mm
• Cabinet matching height: 1770mm
• Refrigerator door height: 992mm
• Freezer door height: 620.5mm
• Minimum ventilation area: 200cm² net cross-sectional area
• Minimum cabinet depth shown in installation guide: 570mm

Product Weight:

• Net product weight: 65kg

Installation & Requirements:

• Installation type: Fully integrated, built-in installation behind customer-supplied cabinetry panels.
• KwikFit system: Manufacturer-designed slide-connect installation system with fixing components supplied.
• Ventilation: Maintain an uninterrupted inlet and outlet airflow path of at least 200cm² net cross-sectional area.
• Electrical supply: Connect to a dedicated, correctly earthed 220–240V outlet using the supplied 10A plug and cord.
• Cabinetry verification: Confirm the current specification sheet, installation manual and physical appliance before cabinetry manufacture or cutting.
• Door panels: Decorative cabinetry door panels are not supplied.
• Door reversal: Left- or right-hand opening can be configured using the supplied hinge components.
• Qualified installation: Installation and service work must follow the manufacturer’s instructions and applicable electrical and building requirements.

Extra Information:

The bottom-mount layout places frequently accessed fresh-food storage above the freezer, while the split shelf and reversible freezer tray allow the internal arrangement to change around taller bottles, serving dishes, pizza boxes and frozen desserts. A dedicated bottle rack, concealed low-temperature compartment and bright LED lighting support organised everyday use without adding external controls or exposed design elements.

The CRZ27011 uses R600a refrigerant and must be installed with the ventilation path specified by Kleenmaid. Because cabinetry panels are supplied separately, the appliance, current dimensional documents and ventilation requirements should be reviewed together with the cabinetmaker before the kitchen is manufactured.

Made In: China

Included Products / Accessories:

• Installation component pack: Includes the cabinet-door sliding attachment blocks, sealing strip and required installation fittings described in the user manual.
• Internal storage: Includes adjustable glass shelves, door trays, bottle rack, low-temperature drawer, fruit and vegetable box, freezer drawers and reversible sliding freezer tray.
• Power connection: Supplied with a 10A plug and cord.
• Cabinetry panels: Not included; the appliance is designed to accept customer-supplied matching kitchen panels.

Warranty:

Kleenmaid appliances are backed by a 5-year factory warranty covering all parts and labour, supported by a national service network. All warranties are in addition to your rights under the Australian Consumer Law.
