Fienza 68703 Winston 75cm Wide Medium Single Bowl Butler Sink

• 60-litre single bowl: provides substantial uninterrupted space for large pots, roasting trays, platters and general kitchen or laundry washing tasks.
• Reversible apron front: may be installed with either the shaker-profile face or the smooth flat face visible, allowing the final presentation to be selected during cabinetry planning.
• Fine fire clay ceramic: manufactured using high-quality European materials to create a substantial ceramic sink body suited to integrated cabinetry installations.
• Fully glazed construction: the sink is glazed on every side for a consistent Gloss White surface across the bowl, rim, apron and exposed exterior.
• Medium 750mm format: combines generous internal capacity with a footprint suited to projects where an 800mm or larger butler sink would be impractical.
• Undermount or flushmount installation: supports two integrated benchtop configurations when installed with the required structural support shelf.
• Deep 215mm bowl: provides useful vertical clearance for washing larger cookware and containing water within the bowl.
• Dedicated basket-waste compatibility: accepts Fienza A3SS, A3CM or A3RB basket wastes, allowing the visible waste finish to coordinate with surrounding tapware and fittings.
• Sink-protector compatibility: designed for use with the optional Fienza A30 protector to create a raised working surface above the ceramic bowl base.

• Product type: medium single-bowl butler sink
• Collection: Winston
• Application: kitchen or laundry
• Bowl configuration: single bowl
• Material: fine fire clay ceramic
• Material source: manufactured using high-quality European materials
• Surface treatment: glazed on all sides
• Colour: Gloss White
• Front profile: reversible shaker or flat apron front
• Installation options: undermount or flushmount
• Nominal product width: 750mm
• Capacity: 60 litres
• Bowl depth: 215mm
• Waste opening: Ø90mm
• Basket waste: required and sold separately
• Compatible basket-waste SKUs: A3SS, A3CM or A3RB
• Structural support: permanent support shelving required
• Manufacturing tolerance: ±15mm
• Optional sink protector: Fienza A30

• Installation type: undermount or flushmount
• Cabinet support: install the sink on permanent structural support shelving capable of carrying its full weight independently of the benchtop.
• Cabinet sizing: allow for a nominal 750mm-wide sink body and confirm that the selected cabinet provides sufficient internal width, structural reinforcement and plumbing clearance.
• Physical-product measurement: complete all final cabinetry, apron opening, benchtop and support measurements using the actual sink received rather than relying solely on the published technical drawing.
• Manufacturing variance: allow ±15mm variation in the width, depth, height and other dimensions of the individual fire clay product.
• Apron orientation: select the shaker or flat face before final positioning and cabinetry completion, as the chosen side will remain exposed towards the room.
• Flushmount positioning: install the sink level with the surrounding benchtop surface and determine the final cut-out from the physical product.
• Undermount positioning: mount the sink beneath the benchtop so the internal bowl aligns with the finished cut-out edge.
• Waste requirement: fit one compatible Fienza basket waste in A3SS, A3CM or A3RB; the basket waste is sold separately.
• Waste aperture: provide for the Ø90mm sink opening and allow sufficient space beneath the bowl for the selected waste, trap and connected pipework.
• Tapware position: plan the sink mixer or tapware separately within the surrounding benchtop or adjoining mounting surface.
• Professional installation: cabinetry, benchtop and plumbing work should be completed by suitably qualified trades using the physical sink and current Fienza documentation as the final installation reference.

Warranty coverage

Fienza is an Australian brand backed by a comprehensive manufacturer's warranty across their full range of bathroom and kitchen products, providing peace of mind and reliable after-sales support.

Residential warranty periods apply. Commercial warranty periods differ, contact Fienza for details. Labour is not included unless otherwise specified.

Mixers & tapware:

• Ceramic disc cartridges: Lifetime — Replacement parts or product, 15 years labour
• Mixer structure: Lifetime — Replacement parts or product, 1 year labour
• Chrome finish: Lifetime — Replacement parts or product, 1 year labour
• PVD finish: 10 years — Replacement parts or product, 1 year labour
• Electroplated finish: 5 years — Replacement parts or product, 1 year labour

Showers:

• Heads, arms & hand pieces (structure): Lifetime — Replacement parts or product
• Rails (structure): Lifetime — Replacement parts or product, 1 year labour on twin showers
• Chrome finish: Lifetime — Replacement parts or product
• PVD & electroplated finish: 5 years — Replacement parts or product

Bath outlets:

• Structure: Lifetime — Replacement parts or product
• Chrome, PVD & electroplated finish: 5 years — Replacement parts or product

Heated towel rails:

• Structure & chrome finish: 15 years — Replacement parts or product, 1 year labour
• PVD finish: 10 years — Replacement parts or product, 1 year labour
• Electrical components: 5 years — Replacement parts or product, 1 year labour

Basins:

• Vitreous china: 5 years — Replacement parts or product, 1 year labour
• Cast stone solid surface (structure): 25 years — Replacement parts or product, 1 year labour
• Cast stone solid surface (finish): 5 years — Replacement product or repair, 1 year labour
• Concrete: 2 years — Replacement parts, 1 year labour

Toilets:

• Vitreous china: 5 years — Replacement parts or product, 1 year labour
• R&T cisterns (tanks & frames): 5 years — Replacement parts or product, 1 year labour
• Viega/Geberit cisterns (tanks & frames): 15 years — Replacement parts or product
• Cistern valves: 3 years — Replacement parts or product, 1 year labour
• Seats, accessories & spare parts: 1 year — Replacement parts or product

Baths:

• Acrylic gloss white (shell): 10 years — Replacement product, 1 year labour
• Resin stone & cast stone solid surface (structure): 25 years — Replacement product, 1 year labour
• Resin stone & cast stone solid surface (finish): 5 years — Replacement product or repair, 1 year labour
• Bath frames & legs: 5 years — Replacement parts, 1 year labour

Sinks:

• Stainless steel & laundry stainless steel: 25 years — Replacement product, 1 year labour
• Granite sinks: 7 years — Replacement product, 1 year labour
• Fire clay ceramic: 5 years — Replacement product, 1 year labour
• PVD coloured sinks: 3 years — Replacement product, 1 year labour

Cabinetry:

• Australian made cabinets (MDF): 10 years — Replacement parts or product, 1 year labour
• Australian made cabinet drawer runners: Lifetime — Replacement parts or product, 1 year labour
• Cabinets (MDF): 5 years — Replacement parts or product, 1 year labour
• Handles, hinges & legs: 5 years — Replacement parts

Vanity tops:

• Vitreous china, poly-marble, solid surface & engineered stone: 5 years — Replacement product, 1 year labour
• Concrete tops: 2 years — Replacement parts or product, 1 year labour
• Timber tops: 1 year — Replacement product, 1 year labour

Mirrors:

• LED mirrors: 5 years — Replacement parts or product, 1 year labour
• Framed mirrors: 3 years — Replacement parts or product
• Standard & Australian made mirrors: 1 year — Replacement parts or product

Accessories:

• Structure, chrome, PVD & electroplated finish: 5 years — Replacement parts or product

Proof of purchase is required for all warranty claims. The warranty applies to the original purchaser only and is not transferable. Warranty periods apply to products purchased on or after 1st September 2023.

What's covered

• Manufacturing defects in materials and workmanship
• Repair or replacement of faulty products
• Replacement of defective parts within the applicable warranty period

What's not covered

• Products installed while incorrect or damaged — damage must be reported before installation
• Incorrect installation or failure to follow manufacturer guidelines
• Misuse, abuse, accidental damage, or neglect
• Normal wear and tear, including rubber seals, O-rings, and washers
• Use of abrasive cleaners, harsh chemicals, or unsuitable cleaning products
• Repairs or modifications carried out by unauthorised parties
• Loss or damage caused by a defective product — only the product itself is covered

Conditions

• Products must be installed by a licensed tradesperson
• Products must be installed and used in accordance with manufacturer instructions
• Products must be inspected before installation — installation is acceptance of goods
• Proof of purchase must be provided with all claims; photos may be required
• The warranty applies to the original purchaser only

Making a claim

For warranty claims after installation, contact Fienza's after-sales service team directly. Claims should be directed through the original place of purchase where possible. Please have your proof of purchase ready when submitting your claim.

Australian Consumer Law

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure.

Fire clay butler sinks are manufactured through a ceramic forming and firing process rather than fabricated to the tighter dimensional consistency associated with pressed metal sinks. Fienza therefore specifies a manufacturing tolerance of ±15mm and states that technical dimensions must be treated as planning guides only.

The sink should be delivered to site before the cabinetry and benchtop are finalised. This allows the installer to confirm the exact product width, apron opening, support height, benchtop relationship and waste position from the individual sink received.

The reversible exterior changes the visual character of the Winston without changing its bowl capacity or installation requirements. The shaker side introduces framed apron detailing, while the flat side provides a cleaner, less decorative presentation. Both sides are fully glazed, enabling the preferred orientation to be selected before the sink is secured.

Fienza identifies the Winston for both kitchen and laundry applications. Its 60-litre capacity provides substantial usable space while the 750mm nominal width offers a more compact alternative to larger butler sinks within the range.
