Artusi AINT8900FDI 90cm Integrated French Door Fridge & Freezer with Ice Maker

• Integrated French door design: A built-in French door refrigerator-freezer made to sit behind your own cabinetry door panels, for a seamless, fully integrated kitchen.
• 439L total net capacity: 278L refrigerator and 161L freezer give generous space for family groceries, entertaining platters and bulk freezing.
• Dual cooling system: Separate cooling systems for the fresh food and freezer compartments keep air and odours from mixing, speed up cooling and defrost each section on its own.
• Chill zone: A temperature-controlled chill zone from -1°C to 3°C keeps meat, fish and delicatessen items at their best.
• Easy-read digital display: Select the zone, temperature and special functions from the digital display, with a lock to prevent accidental changes.
• Built-in ice maker: An automatic ice maker produces up to 1.7 kg of ice per day, switched on or off from the display.
• External water filter: A water filter with a replacement reminder keeps the ice supply fresh.
• 90° flush hinge: A flush hinge lets the doors sit neatly in line with your cabinetry.
• Stainless steel interior: A stainless steel rear wall and door interior with white side walls and grey door bins.
• LED lighting: LED lighting on the side walls, three ceiling panels, the freezer and the drawers shows everything at a glance.
• Quick Cooling, Quick Freezing and ECO: Boost the fridge or freezer after a big shop, or run the economy setting for everyday use. Holiday and Sabbath modes cover time away and religious observance.
• Flexible storage: Three fridge shelves (two adjustable), two crispers, a meat and cheese drawer and six adjustable door bins, plus a large metal freezer drawer and two deep freezer drawers.
• Fast freezing and power failure storage: Freeze up to 7 kg of fresh food in 24 hours, and hold frozen food for up to 11 hours without power.
• Quiet operation: Runs at 41 dBA, suited to open-plan living.

• Fridge temperature: Adjust the refrigerator from 2°C to 8°C. The recommended setting for everyday use is 4°C.
• Chill zone temperature: Adjust the chill zone from -1°C to 3°C.
• Freezer temperature: Adjust the freezer from -15°C to -25°C. The recommended setting for everyday use is -18°C.
• Zone selection: Press the select button to move between the fridge, chill zone and freezer, then set the temperature within 5 seconds.
• Quick Cooling: Runs the refrigerator at 2°C for 24 hours, then returns to the previous setting. Switch it on 4 to 8 hours before loading a large shop.
• Quick Freezing: Runs the freezer at -25°C for 24 hours, then returns to the previous setting.
• ECO mode: Runs the refrigerator at 6°C and the freezer at -16°C to save energy.
• Holiday mode: Runs the refrigerator at 17°C and the freezer at -18°C while you are away.
• Sabbath mode: Switches off the lights and sounds while the refrigerator otherwise runs normally.
• Ice making: Turn the automatic ice maker on or off from the function menu. The ice icon lights while it is making ice.
• Water filter reminder: The water filter symbol flashes after 180 days. After replacing the filter, hold select and power for 3 seconds to reset the reminder.
• Door-open alarm: If a door is left open for 1 minute the alarm sounds until it is closed. Touch any button to silence it, and it sounds again after 1 minute.
• Display lock: Hold the select button for 3 seconds to lock or unlock the display.
• Temperature unit: Hold the function and temperature buttons for 3 seconds to switch between °C and °F.
• Forced defrost: Hold the function and temperature buttons for 5 seconds to start a forced defrost. The appliance returns to its previous setting when it finishes.
• Power on and off: Hold the power button for 3 seconds to switch on or off. After a power interruption the compressor restarts after about 6 minutes.
• Hot-room settings: In ambient temperatures above 30°C use -20°C in the freezer and 3°C in the refrigerator. In hot rooms or with frequent door opening use -24°C and 2°C.

• Brand: Artusi
• Model: AINT8900FDI
• Product Type: 90cm integrated French door refrigerator and freezer with ice maker
• Installation: Built-in, integrated, panel ready
• Total Net Capacity: 439 L
• Refrigerator Capacity: 278 L
• Freezer Capacity: 161 L
• Fridge Temperature Range: 2°C to 8°C
• Chill Zone Temperature Range: -1°C to 3°C
• Freezer Temperature Range: -15°C to -25°C
• Cooling System: Dual cooling, separate fridge and freezer systems
• Controls: Digital display with lock
• Freezing Capacity: 7 kg per 24 hours
• Power Failure Storage: 11 hours
• Noise Level: 41 dB(A)
• Climate Class: T
• Energy Rating: 2.5 stars
• Annual Energy Consumption: 490 kWh per year
• Maximum Door Panel Thickness: 18 mm
• Maximum Door Panel Weight: 7.9 kg fridge door, 9 kg freezer door
• Ice Making Capacity: 1.7 kg per day
• Water Connection: Cold water only, 1.7 to 5.5 bar, 1.5 m of 1/4 inch hose
• Dimensions (W x D x H): 890 x 560 x 1920 mm (without door panel)
• Weight: 155 kg
• Electrical: 10A GPO plug and lead
• EAN: 9347777007292
• Warranty: 2 years parts and labour

• Installation style: Built-in and fully integrated, supplied ready for your own cabinetry door panels.
• Anti-tip brackets: The two anti-tip brackets supplied must be fitted to the wall. This is compulsory.
• Floor and walls: The floor must carry at least 544 kg and be level. Cabinet side walls must be flat, free of obstructions and at least 16 mm thick.
• Door panels: Maximum door panel thickness is 18 mm. Allow a 5 mm gap around the door panels. A 90° limit pin is supplied to restrict how far the doors open.
• Height: Adjustable feet set the appliance height, and the cabinet must be level front to back and side to side.
• Ambient temperature: Climate class T. Install in ambient temperatures of 13°C to 43°C, away from direct sunlight, and in a room that stays above 10°C.
• Clearances: Keep at least 3 cm from an electric hob or oven and 30 cm from a gas hob. Allow 4 cm between two coolers installed side by side.
• Water supply: Connect to a potable cold water supply at 1.7 to 5.5 bar using a one-piece 1.5 m 1/4 inch hose, with an accessible shut-off valve. A reverse osmosis bypass is recommended for the filter.
• Electrical: 10A GPO with a 3-pin plug and lead. The socket must be earthed, accessible after installation, and not on an extension lead or adapter.
• Before use: Allow the refrigerator to stand 3 to 6 hours before switching on, and at least 4 hours if it was transported on its side. Run it empty for 6 hours before loading food.
• Handling: Two people are needed to carry the appliance. Keep the tape on the upper door until it is in the cabinet, as the appliance can tip.

Warranty coverage

Artusi appliances are backed by a comprehensive manufacturer's warranty, providing peace of mind and reliable after-sales support across their full range of kitchen and outdoor appliances.

• Built-in ovens, cooktops, rangehoods, freestanding cookers (900mm) & dishwashers: 2 years — Parts and labour. Extended to 5 years upon product registration.
• Freestanding cookers (50cm, 54cm & 60cm) & portable appliances: 2 years — Parts and labour
• Outdoor BBQs, BBQ lids & beverage chillers: 2 years — Parts and labour (extension not applicable)
• Indoor appliances used in outdoor/alfresco settings: 3 months only

Proof of purchase is required for all warranty claims. Register your product at artusi.com.au to activate the 5-year extended warranty where applicable.

What's covered

• Manufacturing defects in materials and workmanship
• Repair or replacement of faulty products
• Parts and labour within the applicable warranty period

What's not covered

• Damage during shipping, delivery, or installation
• Incorrect installation or failure to follow manufacturer guidelines
• Misuse, abuse, accidental damage, or neglect
• Normal wear and tear or cosmetic damage
• Indoor appliances used in outdoor or alfresco settings
• Repairs or modifications carried out by unauthorised parties
• Commercial use of domestic appliances

Conditions

• Cooktops must be installed by a licensed electrician or licensed gas plumber
• Products must be used and maintained in accordance with manufacturer instructions
• Register your product at artusi.com.au to activate the 5-year extended warranty
• Proof of purchase must be provided with all claims
• Warranty applies to products sold in Australia only

Making a claim

Claims should be directed through the original place of purchase. For after-sales service and warranty support, contact Artusi directly and have your proof of purchase ready when submitting your claim.

Australian Consumer Law

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure.

The AINT8900FDI is the ice maker version of the AINT8900FD and shares its 439L layout. It connects to a cold water supply, so plan the plumbing position before the cabinetry is built.

The ice maker is switched on or off from the display function menu, and the water filter symbol flashes after 180 days to prompt a replacement. A reverse osmosis bypass is recommended when the filter is connected to a reverse osmosis system.

The doors take your own panels up to 18mm thick, and the supplied template helps your cabinetmaker mark out the fixings. The door weight limits are 7.9kg for the fridge door and 9kg for the freezer door.

• Refrigerator-freezer: Artusi AINT8900FDI 90cm integrated French door refrigerator freezer with ice maker
• Shelving and storage: 3 fridge shelves (2 adjustable), 2 crispers, meat and cheese drawer, 6 adjustable door bins, large metal freezer drawer and 2 deep freezer drawers
• Installation kit: 2 anti-tip brackets with screws and dowels, 2 x 90° limit pins, door fixing brackets, hinge slot covers, door and box side trims, furniture door preparation template
• Documentation: User manual and installation manual
