Artusi AINT4100 54cm Integrated Column Freezer

• Integrated column design: A 54cm built-in column freezer made to sit behind your own cabinetry door panel.
• 200L net capacity: Two fixed safety glass shelves with door flaps and five removable drawers keep frozen food organised.
• Temperature range: Adjust the temperature from -14°C to -24°C, with a Super Freeze option for rapid freezing.
• Touch control and LED readout: Set the temperature from the touch panel and read it on the digital LED display.
• Keypad lock: The panel locks after 30 seconds without use, so settings cannot be changed by accident.
• Door open and high temperature alarms: An alarm sounds if the door is left open, and a high temperature alarm warns you if the freezer warms up.
• LED light: An LED light on the underside of the control panel lights the top of the freezer.
• Left-hand hinge, reversible: Supplied with a left-hand hinge, and the door can be reversed to suit your kitchen.
• Fixed hinge door system: Fixed hinges let the door sit neatly behind your cabinetry panel.
• White interior: A clean white interior makes it easy to see what is inside.
• Ice holder tray: A transparent ice holder tray is included.
• Quiet operation: Runs at a maximum of 41 dBA.
• Installation kit: An installation kit is provided for fitting the door panel.

• Freezer temperature: Adjust the freezer from -14°C to -24°C. After the power is first switched on, or restarted after a power failure, the freezer works at -18°C.
• Super Freeze: Select the snowflake setting to run the freezer continuously at -24°C for 24 hours, then it returns to the previous temperature. Switch it on 2 to 3 hours before loading a large amount of fresh food.
• Panel lock: Press the button for 3 seconds to unlock the panel. It locks again after 30 seconds without use.
• Power: Press the power button for 3 seconds to switch the appliance on or off.
• Temperature unit: Switch the display between °C and °F from the panel.
• Sabbath mode: Switch Sabbath mode on or off from the panel for religious observance.
• Door-open alarm: If the door is open for more than 2 minutes, the buzzer sounds every minute, and after 5 minutes it sounds continuously. Press any button to silence it.
• High temperature alarm: If the freezer warms above -1°C after reaching its set temperature, the alarm sounds and the temperature digits flash. Press any button to silence the alarm; the flash stays until the freezer is colder than -1°C.
• Fault display: If a sensor or the control board has a fault, a code (F4, F5 or CE) shows on the display and the freezer keeps working. Call customer care for a service.
• Storage tips: The bottom sections are the coldest. The top two sections have flaps that stay open for loading, and the other five sections are drawers.

• Brand: Artusi
• Model: AINT4100
• Product Type: 54cm integrated column freezer
• Installation: Built-in, integrated, panel ready
• Freezer Capacity: 200 L (net)
• Temperature Range: -14°C to -24°C
• Controls: Touch control with LED readout and digital display
• Storage: 2 fixed safety glass shelves with door flap, 5 removable drawers
• Noise Level: 41 dB(A) maximum
• Refrigerant: R600a
• Energy Rating: 4 stars
• Annual Energy Consumption: 193 kWh per year
• Hinge: Left-hand supplied, reversible, fixed hinge door system
• Dimensions (W x D x H): 540 x 545 x 1770 mm (1776 mm including the top fixing bracket)
• Weight: 62 kg (net)
• Electrical: 220-240V / 50Hz, 10A GPO, 3-pin plug and 1.5 m lead
• EAN: 9347777006226
• Warranty: 2 years parts and labour

• Installation style: Built-in and integrated, supplied ready for your own cabinetry door panel, with an installation kit.
• Hinge side: The left-hand hinge is supplied and the door can be reversed to suit your layout. Reverse the door before fitting the panel, and use a hair dryer from about 10cm away to re-seat the door seal.
• Cabinetry: Designed to fit cabinetry that is 18mm thick.
• Ventilation: Keep the open channel at the rear clear and do not block the top of the housing unit; a 50mm channel depth is normal. A plinth ventilation cut-out of about 300mm x 300mm is recommended, and the cooling system at the rear must not touch the rear wall.
• Levelling: Use the height-adjustable feet at the front to level the appliance.
• Electrical: Connect to a 10A GPO with a 3-pin plug.
• Before use: Let the appliance settle for 24 hours before switching on, and wait 5 minutes before restarting after switching off. The freezer may have an odour at first use, which disappears as it cools.
• Handling: Seek help when installing, and wear protective equipment as the appliance may have sharp edges.

Warranty coverage

Artusi appliances are backed by a comprehensive manufacturer's warranty, providing peace of mind and reliable after-sales support across their full range of kitchen and outdoor appliances.

• Built-in ovens, cooktops, rangehoods, freestanding cookers (900mm) & dishwashers: 2 years — Parts and labour. Extended to 5 years upon product registration.
• Freestanding cookers (50cm, 54cm & 60cm) & portable appliances: 2 years — Parts and labour
• Outdoor BBQs, BBQ lids & beverage chillers: 2 years — Parts and labour (extension not applicable)
• Indoor appliances used in outdoor/alfresco settings: 3 months only

Proof of purchase is required for all warranty claims. Register your product at artusi.com.au to activate the 5-year extended warranty where applicable.

What's covered

• Manufacturing defects in materials and workmanship
• Repair or replacement of faulty products
• Parts and labour within the applicable warranty period

What's not covered

• Damage during shipping, delivery, or installation
• Incorrect installation or failure to follow manufacturer guidelines
• Misuse, abuse, accidental damage, or neglect
• Normal wear and tear or cosmetic damage
• Indoor appliances used in outdoor or alfresco settings
• Repairs or modifications carried out by unauthorised parties
• Commercial use of domestic appliances

Conditions

• Cooktops must be installed by a licensed electrician or licensed gas plumber
• Products must be used and maintained in accordance with manufacturer instructions
• Register your product at artusi.com.au to activate the 5-year extended warranty
• Proof of purchase must be provided with all claims
• Warranty applies to products sold in Australia only

Making a claim

Claims should be directed through the original place of purchase. For after-sales service and warranty support, contact Artusi directly and have your proof of purchase ready when submitting your claim.

Australian Consumer Law

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if they fail to be of acceptable quality and the failure does not amount to a major failure.

The AINT4100 is a freezer only, so it pairs naturally with an integrated column refrigerator such as the AINT5100, with both sitting side by side behind matching panels. It stands on its own 10A power point.

Two alarms look after your food. The door-open alarm sounds after 2 minutes and repeats every minute until the door is closed, and the high temperature alarm flashes the display if the freezer warms above -1°C.

The top two sections have flaps that stay open for easy loading, while the bottom drawers are the coldest part of the freezer, so they suit meat, fish and anything you want to keep longest. Sabbath mode and a Celsius to Fahrenheit switch are available from the panel.

• Freezer: Artusi AINT4100 54cm integrated column freezer
• Shelves and drawers: 2 fixed safety glass shelves with door flaps and 5 removable drawers
• Ice tray: 1 transparent ice holder tray
• Installation kit: Installation kit for the door panel
• Documentation: Operation manual
