Product Description

Product Overview:

The IXL Tastic Luminate Dual 32411 is a premium 3-in-1 bathroom heater, exhaust fan and light built for bathrooms that need stronger radiant heating without compromising ventilation or illumination. Two 800W tungsten-halogen infrared lamps deliver immediate warmth, while the 25W LED panel offers selectable Warm or Cool white lighting.

Its 170mm inline fan extracts up to 480m³/hr and vents moisture outdoors through the supplied six metres of 150mm ducting. The wide white fascia gives the unit a clean architectural presence, while the included Plug & Play wall switch and CAT6 cable make each function straightforward to control.

Designed and manufactured in Australia, the Luminate Dual is suitable for bathrooms up to 10m² with a shower or 25m² without a shower. A one-hour heat timer, automatic thermal fan response and half-heat control provide everyday flexibility and added reassurance.

Product Features:

• Dual 800W infrared heating: Two tungsten-halogen lamps provide powerful, immediate directional warmth.
• Half-heat flexibility: Use one heat lamp when full dual-lamp output is not required.
• High airflow extraction: The 170mm inline fan removes up to 480m³/hr of humid air.
• Warm or Cool LED lighting: The 25W panel switches between 3000K and 4000K illumination.
• Plug & Play wall control: The supplied CAT6-connected switch manages heat, fan and lighting functions.
• Automatic protection: Includes a one-hour heat timer and temperature-responsive fan operation.
• Complete external ducting: Six metres of 150mm duct and an exterior outlet grille are included.
• Australian made: Designed and manufactured in Australia for local bathrooms.

Colour / Finishes:

• White

Programmes / Functions:

• Full heat: Two 800W tungsten-halogen lamps provide maximum directional warmth.
• Half heat: Select one lamp when reduced heating output is more comfortable.
• Ventilation: The 170mm inline fan extracts up to 480m³/hr through external ducting.
• Lighting: The 25W LED panel provides selectable 3000K Warm or 4000K Cool white light.
• Automatic thermal ventilation: The fan can activate automatically when internal temperature rises during heating.
• Heat timer: The heat lamps switch off automatically after one hour.
• Plug & Play control: The supplied CAT6-connected wall switch operates the unit’s functions.

Cleaning & Maintenance:

• Before cleaning: Switch off and isolate the appliance, then allow both heat lamps to cool for at least five minutes.
• Scheduled care: Check and clean the body, fascia and lamps approximately every two years.
• Fascia and air inlet: Use a damp cloth with liquid glass cleaner on the fascia and air inlet.
• Replacement components: Use genuine IXL heat lamps, glass shields and approved LED components.

Specifications:

• Product type: 3-in-1 bathroom heater, exhaust fan and light
• Model: Tastic Luminate Dual 32411
• Barcode: 9332048029028
• Finish: White
• Airflow extraction: 480 m³/hr (133 L/s)
• Fan size: 170 mm
• Heat lamps: 2 x 800W tungsten-halogen infrared
• Half-heat function: Yes
• LED panel: 25W, 3000K Warm / 4000K Cool
• Electrical rating: 230–240V, 50Hz
• Maximum wattage: 1675W (75W fan)
• Ducting: 6 m x 150 mm diameter supplied
• Room suitability with shower: Up to 10 m²
• Room suitability without shower: Up to 25 m²
• Minimum ceiling height: 2.2 m
• Recommended ceiling height: 2.7–3.3 m
• Clearance above unit: 15 mm
• Minimum overall cavity height: 230 mm
• Wall switch: Plug & Play switch included
• IP rating: Not rated
• Ducted: Yes
• Warranty: 5-year in-home unit warranty; 2-year replacement warranty on heat lamps, exhaust fan and LED panel

Product Measurements:

• Unit Dimensions (W x L x D): 367 x 733 x 198 mm
• Fascia Dimensions (W x D): 737 x 365 mm
• Cut-out Dimensions (W x L): 332 x 712 mm
• Minimum Overall Cavity Height: 230 mm

Product Weight:

• Net Weight: 8 kg

Installation & Requirements:

• Installation type: Horizontal ceiling installation with externally ducted inline fan.
• Required trade: Installation must be completed by a qualified electrical tradesperson.
• Cut-out: Provide a 332 x 712 mm ceiling opening.
• Ducting: Use the supplied 6 m x 150 mm duct and exterior outlet grille.
• Electrical control: Connect the supplied Plug & Play wall switch through the CAT6 cable and provide the required local isolating switch.
• Safety: Do not cover the unit with insulation, do not install directly above a shower recess and follow AS/NZS 3000 requirements.

Country of Origin:

• Australia

Extra Information:

The Luminate Dual’s two heat lamps provide strong radiant warmth directly beneath the unit. The centre LED panel switches off while the heat lamps operate and returns automatically when heating is turned off.

Good replacement airflow through the bathroom is essential for effective steam extraction. Open showers and unusually high moisture loads may require supplementary ventilation.

Included Products / Accessories:

• Plug & Play wall switch
• CAT6 control cable
• 2 x 800W tungsten-halogen infrared heat lamps
• 25W Warm/Cool LED panel
• 170mm inline exhaust fan
• 6 m x 150 mm flexible duct
• Exterior outlet grille
• Cut-out template

Warranty:

IXL appliances are backed by a 5-year in-home warranty on all Tastic units, a 3-year warranty on Ventflo exhaust fans, and a 3-year in-home service warranty on Aeroflow ceiling fans. All warranties are in addition to your rights under the Australian Consumer Law.

Downloads / Product Files:

• USER GUIDE (PDF)

• PRODUCT SPECIFICATIONS CHART (JPG)
